Main applications

The DeviceNet system is used for connecting industrial devices (e.g. limit switches, photoelectric switches, inverter drives, motor starters, valve islands, PLCs, etc.) and is based on CAN technology.

DeviceNet Dropping bus cables are mainly used for connecting the branch components of the whole bus system, and are special cables for FA open field network system, which are divided into fixed and mobile use in terms of application.

Industrial Fieldbus Communication Cables

BUS CABLE DeviceNetFD PUR special cable 5-core cable (2 signal cables, 2 power cables, 1 shielded cable) Product Applications

DeviceNet bus system for the connection of industrial equipment. It is a low-cost network connection solution with open network standards. A pair of wires transmits data and a pair of wires supplies power. Suitable for highly flexible applications, drag chain systems, robotic motion systems.

Temperature range

Fixed applications:

PUR:-40°C~80°C

Mobile applications:

PUR: -20℃~70℃

Test Voltage:

1500V/min(AC)

Characteristic Impedance;

120±15Ω@1KHz

Rated voltage:

300V

Cable construction:

Conductor: Fine stranded tinned copper-copper conductor

Insulation: Foamed PE (24AWG), PE (22AWG)

Signal cable color: white, blue (24AWG)

Power cable color: red, black (22AWG)

Shield: wire pair shield, tinned copper total braid

Color: Purple (approx. RAL4001)

PUR jacket

Approximate outer diameter: 7.0mm
